Automatic PP, PE, PS, PVC, PET Plastic Cup Tray packing thermoforming machine
RGC-720 Fully automatic cups machines
- Description
- Inquiry
Description
1st.Main Technical Data
Parameters | Contents |
Material | PP, PE, PS, PVC, PET, ABS, HIPS, degraded material, etc. |
Sheet thickness | 0.3-2.0mm |
Sheet width | 540-700mm |
Max forming area | 650×350mm |
Max forming depth | 130mm |
Work efficiency | ≤30 strokes/min |
Heating rated power | 75KW |
Main motor power | 11kw/6grade |
Power supply | 380V/50Hz 3 phase |
Voltage | 0.6-0.8Mpa |
Air volume required | 2500~3500L/min |
Water volume required | 40~45L/min |
Net weight | About 4500kg |
2nd.Feature
1. Four-pole structure, durable #45 chrome plated steel with good rigidity and abrasion resistance.
2. When a noise reduces ascent and descent of the fluid pressure of the style stand, and shakes.
3. 7 zones automatic temperature controls with error ranges within 1.5°C
4. Immersed ceramics far infrared radiation component. Highly safe and reliable
5. Conveyor chain with gear and double sub-chain. Water-cooling tube in chain way ensures high cooling efficiency and water-saving. Stainless steel board covers the inner machine body. Nitrinized-38CrMoAlA-made chain track guarantees its hardness and durability .
6. Low barycenter and height of finished products as well as steady running ensures easy operation and friendly viewing.
7. Frequency-conversion-driven sheet feeder, high precision sheet feeding with error rate ranging from 1mm to 5mm ensures sheet saving.
8. All motors are overwork-protected.
9. Imported SIEMENS PLC human-machine interface control ensures smooth and exact operation
10. Left-over-sheet reminder installed at the end of the machine with max sheet roll diameter of 0.8m
3rd. Key Electric Components
No | Name | Place and brand | Model |
1 | PLC | SIEMENS | S7-200CN 224CN |
2 | Touch Monitor | WEINVIEW(Tai Wan) | MT6056iv |
3 | Temperature Controller | FC (shanghai) | PXR4TEY1-8W000-C |
Temperature control module | KEJIKEYI (HangZhou) | DTY-H220D150G | |
5 | Transducer | Donfoss | VLT2840P |
6 | Contactor | Schneider | LC1 D3210 LC1 D0910 |
7 | Relay | Omron(Japan) | MY2J 24VDC |
8 | Power Switch | MEAN WELL(Tai Wan) | S-145-24 |
9 | solid state relay | Lingtong (BeiJing) | D210K |
10 | Proximity Switch | Omron | TL-Q5MC1-Z 30VDC |
11 | Air Switch | China | 160A DZ47-63 C63 DZ47-63 C25 DZ47-63 D32 |
12 | Electromagnetically operated valve | (SMC)Japan | VG342-5G-10A VFS4110-5EB-04 VXD2130-04-5G1 |
13 | Electromagnetic Valve | YUKEN (Tai Wan) | DSHG-04-3C2-T-D24-N1 DSHG-04-3C2-T-50 DSG-03-2B8-D24-N1-50 DSG-01-2B2-D24-N1-50 SBSG-06-H-R SBSG-03-H-R |
14 | Heater | Jiangsu | 85X245 220V 650W |
15 | DC motor reduction box | YONGKUN (Tai Wan) | NCH40 1:15 2.2KW |
16 | hydraulic system oil pump | Yu ci | PFED-43085-036-DT0 |
Warranty: We guarantee these machines for one year. And we supply some spare parts with the machine,operation manual and operation CD, etc.
Service: We will send engineer who install and train in your company for approximately 7 to 10 days, after machine is arrived your place. And the flight tickets, visa and accommodation of engineer will be arranged by buyer, also the buyer need pay 80USD/day for training cost.
Delivery Time: It will take within 25-30 days to ship out customer’s goods after get customer’s advance payment.
